Item specifics
  • Supported Operating Systems: Mac os,Windows 8,Windows XP,Windows 7,Windows Vista,Windows 98
  • High Definition: 720P(HD)
  • Power Supply(V): 12
  • IR Distance(m): 10M
  • Brand Name: shrxy
  • Technology: Infrared
  • Connectivity: Closed System/CCTV Wired
  • Minimum Illumination(Lux): 0.01
  • Sensor: CCD
  • Style: Mini Camera
  • Power Consumption(W): 24
  • Sensor Brand: SONY
  • Type: Analog Camera
  • is_customized: Yes
  • Dimensions (L x W x D)(mm): 3*8.5CM
  • Special Features: Vandal-proof
  • Lens (mm): 2.8mm
  • High Definition: 720P(HD)
  • color: Black
  • IR Led: 8pcs ir led
  • lens: 2.8MM
  • type: Mini Outdoor Invisible 8 IR 940nm
  • name: HD MINI camera
  • Viewing Angle (Degree): 115
Product Description

start

end

waterproof Mini CCTV CAMERA 8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Mini Camera WIITH HD 2.8MM Wide-angle LENS



aeProduct.getSubject()aeProduct.getSubject()

aeProduct.getSubject()



aeProduct.getSubject()



8Pcs IR 940nm invisible light lamps,Better Night Vision Effective

aeProduct.getSubject()



aeProduct.getSubject()

Night Vision distance up to 5m, High-definition, grasp details in place.

aeProduct.getSubject()

Waterproof Weatherproof Anti fog

aeProduct.getSubject()

Features:

mage Sensor: 1/3" Sony Super HAD CCD II
DSP: Effio-E (4140+811/810)
Horizontal Resolution :700TVL

Effective Pixel:NTSC:976(H) X494(V) PAL:976(H) X582(V)

Min. Illumination :0.001 Lux (F1.2)/ 0 Lux IR On
Signal System: NTSC/PAL
Lens: Standard 2.8mm
Camera Type: Indoor/Outdoor
Power Supply: DC12V/75MA



Packing list:
1 x Mini Bullet Wide-angle Camera
1 x Camera bracket with screws
1 x Retail Box

Specification Of the Camera:

Model

RX700BT

Image Sensor

1/3" Sony Super HAD CCD II

DSP

Effio-E (4140+811/810)

Horizontal Resolution

Color Mode: 650TVL; B/W Mode:700TVL

Effective Pixel

NTSC:976(H) 494(V) PAL:976(H) 582(V)

Min. Illumination

0.001 Lux (F1.2)/ 0 Lux IR On

Signal System

NTSC/PAL

Electronic Shutter

NTSC:1/60~1/100,000, PAL:1/50~1/110,000

S/N Ratio

More than 48dB

Gamma

0.45/1.0

Exposure

Auto

OSD

Support

White Balance

ATW / User1/User2

Backlight

OFF/ON/BLC/ HLC

Pic Adjust

Mirror/Brightness/Contrast/Sharpness/Hue/Gain

ATR

ON/OFF

D-WDR

Yes

Motion Det

OFF/ON(Detect sense/ Area Sel)

Privacy Masking

OFF/ON (4 Zone)

Day/Nigh

True Day and Night (Auto/ Day / Night / Ext. D&N)

2D-NR

OFF/ON (0-15/16 level)

Camera ID

OFF/ON

Sync. System

Internal

Audio Output

Optional

Video Output

1 Vp-p / 75 Ohms

Working Conditions

-20~60Degree/0-93% Humidity

Power Supply

DC12V/75MA



Note: 3.6mm lens, PAL SYSTEM,Black housing color default for this camera. If the buyer want other size lens,other system,other color, please Leave Message to notify us when bidding.



Trouble and Solution:



1. No Picture after providing power
May be the power supply voltage abnormity, please check the power supply voltage and pole whether exactitude.
Please check all the conecting cable and monitors whether be connected correctly or not.

2. The picture level direction have flowing interference ripples
May be caused by the power supply AC ripples, it need filter the wave of the power supply.
Check the monitor and peripheral equipments used.

3. The picture background color changes continuously
The fluorescent lamp\\\'s electromagnetic field cause color roll. This is proper phenomenon of the cameras.
Reduce the fluorescent lamp numbers or increase the distance between the camera and the fluorescent lamps can
improve it.
Use Power supply external sync. Camera can solve it.

4.The picture smear too mass
The power supply\\\'s voltage unstable
Connecting cables not connect correctly or have high impedance.





Trouble and Solution:

PS: PAL format is for Euro Courty, NTSC format is for USA, Canada,
if you don\\\'t know which one you need, please feel free to contact us.

1. No Picture after providing power
May be the power supply voltage abnormity, please check the power supply voltage and pole whether exactitude.
Please check all the conecting cable and monitors whether be connected correctly or not.

2. The picture level direction have flowing interference ripples
May be caused by the power supply AC ripples, it need filter the wave of the power supply.
Check the monitor and peripheral equipments used.

3. The picture background color changes continuously
The fluorescent lamp\\\'s electromagnetic field cause color roll. This is proper phenomenon of the cameras.
Reduce the fluorescent lamp numbers or increase the distance between the camera and the fluorescent lamps can
improve it.
Use Power supply external sync. Camera can solve it.

4.The picture smear too mass
The power supply\\\'s voltage unstable
Connecting cables not connect correctly or have high impedance.

aeProduct.getSubject()

aeProduct.getSubject()

aeProduct.getSubject()

aeProduct.getSubject()aeProduct.getSubject()

waterproof  Mini CCTV CAMERA  8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Mini Camera WIITH HD Wide-angle LENS

waterproof  Mini CCTV CAMERA  8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Mini Camera WIITH HD Wide-angle LENS

Packaging Details
  • Unit Type: piece
  • Package Weight: 0.4kg (0.88lb.)
  • Package Size: 15cm x 12cm x 12cm (5.91in x 4.72in x 4.72in)
