Report item
Item specifics
  • Dimensions (L x W x D)(mm): mm*mm
  • Alarm Action: FTP Photo,Email Photo
  • Technology: Infrared
  • IR Distance(m): 25-35m
  • Minimum Illumination(Lux): 0.01
  • Sensor: CMOS
  • Supported Mobile Systems: iPhone OS,Android
  • Brand Name: MISECU
  • Supported Operating Systems: Windows 7,Windows 8,Windows XP
  • Wall Bracket: Side
  • Video Compression Format: H.264
  • High Definition: 1080P(Full-HD)
  • Special Features: Waterproof / Weatherproof
  • Color: White
  • is_customized: No
  • Power Supply(V): DC12V
  • Type: IP Camera
  • Sensor Brand: SONY
  • Installation: Ceiling
  • Connectivity: IP/Network Wired
  • Model Number: YN-IPC-BT635Z-20
  • Power Consumption(W): 6W-7W
  • Style: Bullet Camera
  • Network Interface: RJ-45 10/100Mb Ethernet Slot
  • Audio Output: NO
  • Lens (mm): 2.8-12mm Auto Zoom
  • Features: Waterproof / Weatherproof ONVIF 2.0 P2P
  • Image Sensor: 1/ 2.8" CMOS
  • Image Output: 1920 *1080 full HD
  • Specialty: Auto Zoom lens 2.8-12mm Outdoor/Indoor
  • Type: Bullet ( Metal housing) Infrared
  • Color: White
  • Leds: 2 pcs Array IR CUT
  • Chip: HI3516C+SONY IMX222
  • Technology: super wide dynamic CMOS sensor
  • Ships From: Guangdong,China
Product Description

Auto Zoom lens 2.8-12mm 2.0MP FULL IP Array camera wide dynamic CMOS HD Onvif P2P NIght Vision Camera Camera cctv home security

Overview :

2.0MP .jpg2.0MP 2.jpg

2.0 Megapixel HD IR Bullet outdoor indoor Onvif  IP Camera ,Auto zoom 2.8-12 mm ,new

super wide dynamic CMOS sensor



Dual H.264,dual-stream enconding

1920*1080 ( Main Stream )

2pcs high power array leds ,

IR-CUT filter Built In

IR Distance 3-35 Meters.

Metal Housing ( Waterproof )

0.45 grams apprx

dbkgjIMG_0968008009



Image Capture

Video Res

1080P HD (1920 x1080 pixels)

Color

white default

Use Location

Outdoor and Indoor

Use For

Standard and Professional

Image Sensor

Image sensor

1/2.7" Progressive

Resolution

Megapixel 1080P

Min Illumination

Color: 0.01Lux F1.2, B/W: 0.001Lux F1.2

Lens

Type

Glass Lens

Size

Auto zoom lens 2.8-12mm

Aperture

f 1.2

Interface

Communication Interface

1 RJ45 10M / 100M ethernet port

DC

Yes

Domain Name

Server

P2P Server/ DDNS server/RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP

Video

Image Compression

H.264

Resolution

1920 x 1080

Image settings

Saturation, brightness, contrast adjustable through client software or web browser

Video Parameters

Contrast, Brightness, Saturation, Hue




day



How We Pack :

1x 1080P HD IP camera Auto zoom 2.8-12mm lens

Screw

Installation CD

us_cvpromo_01

coupon11.11



Thanks for feedback with photos, provided from my customers: Evge*******ikov 635Z-20
Thanks for feedback with photos , provided from my customers : Niko****YEV

635ZZ635-



Warm Reminder :

To connect camera to computer ,

You need to modify computer\'s IP address so that the camera is connected to the LAN, generally, camera and the router or the computer must be on the same network segment, such as:

    IP address of the router or computer is 192.168.1.1

    camera\'s IP address must be in the 192.168.1.1~254 range

Factory default setting network parameters of the camera:

IP address:192.168.1.10

Subnet Mask:255.255.255.0

Gateway:  192.168.1.1

PORT:34567

FAQ:

1.Camera cannot be found

If the camera is connected, but cannot the find the camera, you can check according to the following steps:
    1. Confirm the camera and the computer is in the same local area network (LAN)
    2. Whether installed relative CMS software
    3. The routers and switches the function or Settings for blocking of the radio signal

    4. Check whether the cable is aging, or Ethernet cable is too long lead to signal transmission





IE Cloud Security-Video Management System make it easy to monitor what you care no matter where you are!

TOP Picks

NewIP-Camera-511s7932f8908TQW4W4S-BT621AW7904FN-561-10W8W8S-BT619AW

To get a $16 coupon right now! Exclusively usable on 00:00-23:59 on 11.11 only!

AliExpress Selected Coupon accepted by MISECU Official Store: $2 coupon for $19 orders.

Coupon: https://misecu.aliexpress.com/store/sale-items/712315.html



12345678910



newest 6



IP Camera Monitoring System

(D8(IMD7MCAQEUB062[Q(~OQ(11CRV60PP{`]7V13X{WPQ

HTB1GHjJIXXXXXaPXFXXq6xXFXXXaHTB14m2UIXXXXXaoXpXXq6xXFXXXe

How to reset the camera configuration:

reset 1reset 2reset 3reset 4You may need:
